TECHNICAL PARAMETERS:

                Working Frequency: 13.56MHz

                Power Supply: DC 24V

                Data Transmission Standard:13.56MHz: ISO14443A

                Reading Range: ≤5CM

                Read/Write Function: Read/Write

                Power Consumption: < 1W

                Communication Interface: RS485

                Data Transfer Rate: 9600（N，8，1）

                Working Temperature: -10℃— 60℃

                Button Material: Capacitive touch keyboard

                Protection Standard: IP54

                Color: Sliver

                Dimension(L×D×H): 96*67*19mm

                Installation Size: 90*58mm

                Installation Depth: 20mm

                TECHNICAL PARAMETERS:

                Working Frequency: 13.56MHz

                Power Supply: DC 24V

                Data Transmission Standard:13.56MHz: ISO14443A

                Reading Range: ≤5CM

                Read/Write Function: Read/Write

                Power Consumption: < 1W

                Communication Interface: RS485

                Data Transfer Rate: 9600（N，8，1）

                Working Temperature: -10℃— 60℃

                Button Material: Capacitive touch keyboard

                Protection Standard: IP54

                Color: Champaign Gold

                Dimension(L×D×H): 96*67*19mm

                Installation Size: 90*58mm

                Installation Depth: 20mm

                TECHNICAL PARAMETERS:

                Working Frequency: 13.56MHz

                Power Supply: DC 24V

                Data Transmission Standard:13.56MHz: ISO14443A

                Reading Range: ≤5CM

                Read/Write Function: Read/Write

                Power Consumption: < 1W

                Communication Interface: RS485

                Data Transfer Rate: 9600（N，8，1）

                Working Temperature: -10℃— 60℃

                Protection Standard: IP54

                Color: Sliver

                Dimension(L×D×H): 96*67*19mm

                Installation Size: 90*58mm

                Installation Depth: 20mm

                TECHNICAL PARAMETERS:

                Working Frequency: 13.56MHz

                Power Supply: DC 24V

                Data Transmission Standard:13.56MHz: ISO14443A

                Reading Range: ≤5CM

                Read/Write Function: Read/Write

                Power Consumption: < 1W

                Communication Interface: RS485

                Data Transfer Rate: 9600（N，8，1）

                Working Temperature: -10℃— 60℃

                Protection Standard: IP54

                Color: Champaign Gold

                Dimension(L×D×H): 96*67*19mm

                Installation Size: 90*58mm

                Installation Depth: 20mm

                TECHNICAL PARAMETERS:

                Working Frequency: 13.56MHz

                Power Supply: DC 24V

                Data Transmission Standard:13.56MHz: ISO14443A

                Reading Range: ≤5CM

                Read/Write Function: Read/Write

                Power Consumption: < 1W

                Communication Interface: RS485

                Data Transfer Rate: 9600（N，8，1）

                Working Temperature: -10℃— 60℃

                Protection Standard: IP54

                Shell Material: ABS+Aluminum alloy frame

                Color: Sliver

                Dimension(L×D×H): 82*44*4.5mm,94*62*20mm

                Installation Size: 90*58mm

                Installation Depth: 20mm

                Drilling Diameter: 30mm*1,4mm*4

                TECHNICAL PARAMETERS:

                Working Frequency: 13.56MHz

                Power Supply: DC 24V

                Data Transmission Standard:13.56MHz: ISO14443A

                Reading Range: ≤5CM

                Read/Write Function: Read/Write

                Power Consumption: < 1W

                Communication Interface: RS485

                Data Transfer Rate: 9600（N，8，1）

                Working Temperature: -10℃— 60℃

                Protection Standard: IP54

                Shell Material: ABS+Aluminum alloy frame

                Color: Sliver

                Dimension: 49*H2.5mm(outer panel);94*62*20mm(back cover)

                Installation Size: 90*58mm

                Installation Depth: 20mm

                Drilling Diameter:45mm*1
